ADK-6120: HI-6120 MIL-STD-1553 Remote Terminal Developer’s Kit

The HI-6120 Remote Terminal Developer’s Kit is a reference design for a MIL-STD-1553B Remote Terminal with on-board bus interface transformers for connection to a MIL-STD-1553 bus. The HI-6120 kit uses a 16-bit parallel bus interface to a Zilog® ZNEO^TM microprocessor. The Zilog® ZNEO^TM microprocessor can be programmed using the supplied Zilog® USB “Smart Cable”. The board also includes two external flash EEPROM devices which can be used for automatic initialization.

Downloads

Application Notes

AN-550 Rev. A - updated 10/5/2023
AN-551 Rev. New - updated 4/26/2016
AN-573: HI-6120/21 to MAMBA Software Porting Guide Rev. New - updated 8/5/2016

Data Sheets

HI-6120 Rev. M - updated 6/9/2023

Demo Kit Quick Start Guide

QSG-6120 Rev. New - updated 5/24/2011

Demo Kit User Guide

AN-6120 Rev. A - updated 5/20/2011

Software Guide

AN-560: RT GUI User Guide Rev. A - updated 9/11/2015
AN-570: RT Software Migration Guide Rev. New - updated 9/12/2015
